Specifications of Aluminum Coil
Products Name | Aluminium Coil |
Alloy/Grade | 1050, 1060, 1070, 1100, 1200, 2024, 3003, 3104, 3105, 3005, 5052, 5754, 5083, 5251, 6061, 6063, 6082, 7075, 8011, 8079, 8021 |
Temper | F, O, H | MOQ | 5T for customized, 2T for stock |
Thickness | 0.014mm-20mm | Packaging | Wooden Pallet for Strip & Coil |
Width | 60mm-2650mm | Delivery | 15-25days for production |
Material | CC & DC route | ID | 76/89/152/300/405/508/790/800mm |
Type | Strip, Coil | Origin | China |
Standard | GB/T, ASTM, EN | Loading Port | Any port of China, Shanghai & Ningbo & Qingdao |
Surface | Mill Finish, Anodized, Color coated PE Film Available | Delivery Methods | By sea: Any port in China |
Aluminum Alloy Grade of Aluminum Coil
Alloy Series | Typical Alloy | Introduction |
1000 Series | 1050 1060 1070 1100 | Industrial Pure Aluminum. Of all series, the 1000 series belongs to the series with the largest aluminum content. The purity can reach over 99.00%. |
2000 Series | 2024(2A12), LY12, LY11, 2A11, 2A14(LD10), 2017, 2A17 | Aluminum-copper Alloys. 2000 series is characterized by high hardness, in which the content of copper is the highest, about 3-5%. |
3000 Series | 3A21, 3003, 3103, 3004, 3005, 3105 | Aluminum-manganese Alloys. 3000 series aluminum sheet is mainly composed of manganese. The manganese content ranges from 1.0% to 1.5%. It is a series with a better rust-proof function. |
4000 Series | 4A03, 4A11, 4A13, 4A17, 4004, 4032, 4043, 4043A, 4047, 4047A | Al-Si Alloys. Usually, the silicon content is between 4.5 and 6.0%. It belongs to building materials, mechanical parts, forging materials, welding materials, low melting points, and good corrosion resistance. |
5000 Series | 5052, 5083, 5754, 5005, 5086,5182 | Al-Mg Alloys. 5000 series aluminum alloy belongs to the more commonly used alloy aluminum series, the main element is magnesium, and the magnesium content is between 3-5%. The main characteristics are low density, high tensile strength, and high elongation. |
6000 Series | 6063, 6061, 6060, 6351, 6070, 6181, 6082, 6A02 | Aluminum Magnesium Silicon Alloys. The representative 6061 mainly contains magnesium and silicon, so it concentrates on the advantages of the 4000 series and 5000 Series. 6061 is a cold-treated aluminum forging product, which is suitable for applications requiring high corrosion resistance and oxidation resistance. |
7000 Series | 7075, 7A04, 7A09, 7A52, 7A05 | Aluminum, Zinc, Magnesium, and Copper Alloys. The representative 7075 mainly contains zinc. It is a heat-treatable alloy, belongs to super-hard aluminum alloy, and has good wear resistance. 7075 aluminum plate is stress-relieved and will not deform or warp after processing. |
Features of Aluminum Coil
1. Good temperature resistance
The melting point of aluminum is 660 degrees, and the general temperature does not reach its melting point.
2. Excellent Corrosion resistance
Because of its tight surface oxide film, it has strong adhesion, oxidation resistance, acid resistance, alkali resistance, corrosion resistance, decay resistance, and UV resistance.
3. Color uniform, long-lasting, even, and delicate
Soft and colorful, avoiding the individual chromatic aberration of traditional spraying, no matter how large the ceiling, its color, and color are consistent, lasting, and new.
4. Rigid joint, extremely high strength of the board
Rigid and tough combination, free to cut, slit, arc, balance, drilling, joint fixation, and edge compression molding.
5. Environmental protection
Not easy to turn yellow, using chromium-free treatment liquid to make up for the defects of easy discoloration of the laminating board; the roller paint contains active chemical molecules, which promote the formation of a protective layer on the surface of the material. Active chemical molecules are stable and easy to recycle, meeting environmental requirements.
1)1000 Series Alloy (Generally called commercial pure aluminum,Al>99.0%) |
Purity | 1050 1050A 1060 1070 1100 |
Temper | O/H111 H112 H12/H22/H32 H14/H24/H34 H16/H26/H36 H18/H28/H38 H114/H194, etc. |
Specification | Thickness≤30mm; Width≤2600mm; Length≤16000mm OR Coil (C) |
Application | Lid Stock, Industrial Device, Storage, All Kinds of Containers, etc. |
Feature | Lid Shigh conductivity, good corrosion resistant performance, high latent heatof melting, high-reflectance, well welding property, low strength, and notsuitable for heat treatments. |
2)3000 Series Alloy (Generally called Al-Mn Alloy, Mn is used as main alloy element) |
Alloy | 3003 3004 3005 3102 3105 |
Temper | O/H111 H112 H12/H22/H32 H14/H24/H34 H16/H26/H36 H18/H28/H38 H114/H194, etc. |
Specification | Thickness≤30mm; Width≤2200mm Length≤12000mm OR Coil (C) |
Application | Decoration, heat-sink device, external walls, storage, sheets for construction, etc. |
Feature | Good rust resistance, not suitable for heat treatments, good corrosion resistantperformance, well welding property, good plasticity, low strength but suitablefor cold working hardening |
3)5000 Series Alloy (Generally called Al-Mg Alloy, the Mg is used as main alloy element) |
Alloy | 5005 5052 5083 5086 5182 5754 5154 5454 5A05 5A06 |
Temper | O/H111 H112 H116/H321 H12/H22/H32 H14/H24/H34H16/H26/H36 H18/H28/H38 H114/H194, etc. |
Specification | Thickness≤170mm; Width≤2200mm ; Length≤12000mm |
Application | Marine Grade Plate, Ring-Pull Can End Stock, Ring-Pull Stock, AutomobileBody Sheets, Automobile Inside Board, The Protective Cover On Engine. |
Feature | All the advantages of normal aluminium alloy, high tensile strength & yield strength,good corrosion resistant performance, well welding property, well fatigue strength,and suitable for anodic oxidation. |
4)6000 Series Alloy (Generally called Al-Mg-Si Alloy, the Mg and Si are used as main alloy elements ) |
| Alloy | 6061 6063 6082 |
Temper | O F, etc. |
Specification | Thickness≤170mm; Width≤2200mm ; Length≤12000mm |
Application | Automotive, Aluminium For Aviation, Industrial Mould, Mechanical Components,Transport Ship, Semiconductor Equipments, etc |
Feature | Good corrosion resistant performance, well welding property, good oxidability,easy to spray-finishing, well oxidation coloring, good machinability. |
Main Application
1. It is used as a decorative material.
2. Used to make profiles such as door and window frames and window sashes
3. In the construction industry, it can be used as building materials, mechanical parts and architectural decorations.
4. Used as a conductor to make artificial metal.
5. It can be made into rods and tubular parts, which are widely used in the instrument industry.
6. It can be used as precision casting aluminum alloy ingot.
7. It can be used to make automobile fuel tanks.
8. Can be used as mold material.
9. Can be used in the chemical industry.
10. Can be used in the machinery industry.
